Transmission: Countershaft power-shift, 4F/2R
Max speed: 37 km/h (F), 28 km/h (R)
Dimensions: 7170 × 2484 × 3235 mm
Wheelbase: 2700 mm
Wheel tread: 1856 mm
Ground clearance: 340 mm
Turning radius: 5100–5920 mm
Steering: Articulated, 36° steering angle
Bucket capacity: 1.7 m³
Tipping load (full turn): 6000 kg
Breakout force: 105 kN
Dump height: 3057 mm
Dump reach: 906 mm
Max hinge height: 3980 mm
Dig depth (bucket level): 62 mm
Hydraulic system: Gear pump, 16 MPa
Lift time: 5.1 s
Cycle time: 9.0 s
Fuel tank: 150 L
Hydraulic oil: 160 L
Engine oil: 18 L, Transmission oil: 38 L
Axle oil: 18 L ×2
Cooling system: 26 kg
Tires: 17.5-25 L3
Axles: Conventional front & rear, ±12° oscillation
Brakes: Air-over-hydraulic service brake, mechanical parking brake
Uses: loading, quarry work, material handling, construction sites, earthmoving, road works, aggregate loading
